Dimension (Dx Wx H) |
150mm(L) ×81.5mm(W) × 40.5mm(H) |
|||||
AC input (AC IN) |
100-240V /3-1.3A/60-50HZ |
|||||
DC output |
+3.3V |
+5V |
+12V1 |
+12V2 |
-12V |
+5Vsb |
13A |
14A |
14A |
14A |
0.3A |
2A |
|
maximum |
+5V&+3.3V Maximum combined output power not exceeding 80W |
|||||
Main Power Interface |
20+4Pin |
|||||
12V Auxiliary power supply interface |
4pin |
|||||
Mini 4 Pin floppy interface |
1 |
|||||
SATA |
2 |
|||||
IDE 4Pin interface |
2 |
|||||
Fans |
40MM Silent fan, with fan speed control function |
|||||
security certificate |
3C、CE、FCC、CB、UL、NEMKO、ROHS |
